PEQ2R

PEQ2R - 19" Rack Mount -

The PEQ2R mic-pre/equalizer is the 19" rack mount version of the PEQ2. It has a conductive plastic logarithmic taper output level potentiometer, which acts as an output fader, a 48V phantom power switch and a quarter inch instrument input jack. We've taken the PEQ1R and enhanced it to make it even better!

PEQ2R New Features:

  • NEW output stage added to the tail end, just before output transformer, for greater maximum gain.
  • Upgraded "NICO" transformers (Nickle/Iron/Cobalt).
  • Improved Gain switches with over 3 x the gold contact area per switch position.
  • Improved EQ switches with over 3 x the gold contact area per switch position.
  • Light pipe pushbuttons, as used in the Wunderbar Console.
  • Discrete, active high pass filter.
  • LED metering with Green signal indicator and Red clip light.
  • 1/4" instrument input is selectable from Active or Classic Input on PEQ2R.
  • Gain knob now has one extra counterclockwise position to achieve -6db less gain (-24dB instead of -18dB like on old units).
  • Totally redesigned enclosure with thicker gauge metal for superior shielding and better RF protection.
  • Thicker faceplate on PEQ2R.
  • 1% Metal Film resistors for lower noise floor and better matching from channel to channel.
  • Sturdier amp compensation or RF rejection capacitors.
  • New PCB with revised and optimized component layout with beefier traces.
  • RF filtering.

Accessories: BLUE BOX PSU, BLACK BOX PSU
